MATRIX HIGH PERFORMANCE 7.4V 1800mAh 15C BRICK TYPE AIRSOFT LiPo BATTERY – SMALL TAMIYA

1800mAh Capacity • 15C Continuous / 25C Burst • Compact Brick Design • Small Tamiya Connector • AEG Power Upgrade

7.4V LiPo POWER // 1800mAh CAPACITY // 15C CONTINUOUS // 25C BURST // SMALL TAMIYA // AEG READY

Give your compatible AEG a compact, efficient power source with the Matrix High Performance 7.4V 1800mAh Brick Type Airsoft LiPo Battery with Small Tamiya Connector.

Designed specifically for Airsoft AEG rifles and other compatible electric airsoft platforms, this Matrix battery combines a 7.4V LiPo configuration, 1800mAh capacity, 15C continuous discharge rate, and 25C burst output in a compact brick-style package measuring approximately 104mm × 35mm × 15mm.

For players moving from older NiMH battery technology or looking for a dependable 7.4V LiPo for a compatible AEG, this battery provides a practical balance between capacity, compact dimensions, power delivery, and runtime without stepping into the more aggressive voltage characteristics of an 11.1V LiPo.

01 // 7.4V LiPo POWER FOR AIRSOFT AEGs

The Matrix battery uses a 7.4V Lithium Polymer configuration designed to power compatible Airsoft AEG systems.

LiPo batteries have become extremely popular in airsoft because they can provide strong power delivery in a relatively compact package.

Compared with many traditional battery configurations, LiPo technology can offer a useful combination of small physical size, efficient output, and responsive electrical performance.

A 7.4V configuration is especially popular for players looking for LiPo performance without necessarily moving to a higher-voltage 11.1V setup.

Always confirm that your specific AEG and electronic system are compatible with LiPo batteries before use.

02 // 1800mAh CAPACITY

Battery capacity plays an important role in determining how long an AEG can operate between charges.

This Matrix battery provides 1800mAh of capacity, giving it a useful balance between runtime and physical size.

For many players, 1800mAh provides enough capacity for extended gameplay while remaining compact enough to fit inside compatible stocks, battery compartments, and external battery spaces.

Actual runtime varies significantly depending on the AEG.

Motor efficiency, spring load, gear ratio, firing habits, electrical resistance, temperature, and overall drivetrain setup can all affect how quickly a battery is discharged.

03 // 15C CONTINUOUS / 25C BURST OUTPUT

This Matrix LiPo is rated for:

15C Continuous Discharge
25C Burst Discharge

The discharge rating indicates the battery’s ability to deliver current when demanded by the AEG.

This is particularly important during motor startup, when the gearbox is cycling, and when the drivetrain is under load.

A properly matched battery can contribute to cleaner electrical performance and responsive AEG operation.

However, battery performance should always be matched to the electrical and mechanical requirements of the specific airsoft gun.

04 // COMPACT BRICK-TYPE CONFIGURATION

Battery specifications only matter if the pack actually fits inside your airsoft gun.

This Matrix model uses a compact brick-type layout measuring approximately:

104mm × 35mm × 15mm

The rectangular profile makes it suitable for compatible AEG battery compartments designed to accommodate brick-style packs.

Before purchasing, measure the available battery compartment inside your rifle and leave sufficient space for the wiring and connector.

Never force a LiPo battery into a compartment that is too small, as crushing, puncturing, or excessively bending a LiPo pack can create a serious safety hazard.

05 // SMALL TAMIYA CONNECTOR

This version comes equipped with a Small Tamiya power connector.

Small Tamiya connectors remain common across a wide range of factory Airsoft AEGs, making this battery suitable for compatible rifles that retain their original-style wiring configuration.

Always confirm your AEG’s connector before ordering.

This battery is specifically the:

Small Tamiya version

and should not be confused with Deans / T-Plug, XT-series, or other connector configurations.

06 // BMS / XH 3-PIN BALANCE CONNECTOR

For charging, the battery incorporates a BMS / XH 3-pin charging connector.

A proper LiPo-compatible balance charger uses the balance connection to correctly manage the individual cells within the battery pack.

This battery should be charged only with a charger specifically designed for compatible Lithium Polymer batteries.

A charger is not included.

Do not attempt to charge this battery using a charger intended only for NiMH, NiCd, or other incompatible battery chemistries.

07 // BUILT FOR RESPONSIVE AEG PERFORMANCE

Matrix positions this battery as a high-performance power source for compatible Airsoft AEGs.

A properly matched LiPo battery can support responsive motor operation and efficient gearbox cycling, particularly compared with an aging or underpowered battery.

Final AEG performance, however, is determined by the complete electrical and mechanical system.

The motor, gear ratio, spring, wiring, trigger contacts or MOSFET/ETU, connector type, and battery all work together.

Think of the battery as part of the drivetrain—not a standalone performance modification.

WHY CHOOSE THE MATRIX 7.4V 1800mAh LiPo?

✓ 7.4V LiPo CONFIGURATION

A popular voltage for compatible Airsoft AEG platforms.

✓ 1800mAh CAPACITY

Balances useful runtime with manageable physical dimensions.

✓ 15C CONTINUOUS OUTPUT

Provides steady current delivery during normal operation.

✓ 25C BURST OUTPUT

Supports short periods of increased current demand.

✓ COMPACT BRICK DESIGN

Approximately 104mm × 35mm × 15mm.

✓ SMALL TAMIYA CONNECTOR

Compatible with many factory-wired AEG configurations.

✓ 3-PIN BALANCE CONNECTION

Designed for use with an appropriate LiPo balance charger.

LiPo SAFETY // CHARGE, STORE & HANDLE CORRECTLY

LiPo batteries require proper handling. Use only a compatible LiPo balance charger, inspect the battery before use or charging, and discontinue use if the pack becomes damaged, swollen, punctured, or otherwise abnormal.

Charge LiPo batteries on a non-flammable, heat-resistant surface in an appropriate LiPo charging bag or container, and never leave a charging battery unattended.

Avoid crushing, puncturing, short-circuiting, overheating, or completely over-discharging the battery. Follow the battery and charger manufacturers’ instructions for charging and storage.

FINAL WORD // COMPACT 7.4V POWER FOR YOUR AEG

The Matrix High Performance 7.4V 1800mAh 15C Brick Type Airsoft LiPo Battery with Small Tamiya Connector delivers a practical combination of capacity, compact dimensions, discharge capability, and broad AEG usefulness.

With its 1800mAh capacity, 15C continuous / 25C burst output, 104mm × 35mm × 15mm brick profile, Small Tamiya connector, and dedicated 3-pin balance connection, it’s a strong choice for compatible AEG owners looking for a dependable 7.4V LiPo power source.

MATRIX // 7.4V // 1800mAh // 15C / 25C // SMALL TAMIYA // AEG POWER
